Selection Guide
Po (mW/sr) [2]
Viewing
Part No.
Dice
Lens Type
@ 20mA *50mA
Min.
Typ.
Angle [1]
2 θ 1/2
WP3A10SF7C
SF7 (GaAlAs)
Water Clear
7
*10
18
*45
50 °
Notes:
1. θ 1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value.
2. * Luminous intensity with asterisk is measured at 50mA;Radiant Intensity/ luminous flux: +/-15%.
Electrical / Optical Characteristics at TA=25°C
Parameter
Forward Voltage [1]
P/N
SF7
Symbol
V F
Typ.
1.4
Max.
1.6
Units
V
Test Conditions
I F =20mA
Reverse Current
Capacitance
Peak Spectral Wavelength
Spectral Bandwidth
SF7
SF7
SF7
SF7
I R
C
λ P
Δλ 1/2
30
850
50
10
uA
pF
nm
nm
V R = 5V
V F =0V;f=1MHz
I F =20mA
I F =20mA
Note:
1. Forward Voltage: +/-0.1V.
Absolute Maximum Ratings at TA=25°C
Parameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating Temperature
Storage Temperature
Lead Solder Temperature [2]
Lead Solder Temperature [3]
Symbol
P D
I F
i FS
V R
T A
T STG
SF7
80
50
1
5
-40 To +85
-40 To +85
260°C For 3 Seconds
260°C For 5 Seconds
Units
mW
mA
A
V
°C
°C
Notes:
1. 1/100 Duty Cycle, 10 μ s Pulse Width.
2. 2mm below package base.
3. 5mm below package base.
SPEC NO: DSAL0493
APPROVED: WYNEC
REV NO: V.1
CHECKED: Allen Liu
DATE: AUG/10/2010
DRAWN: F.F.Zhou
PAGE: 2 OF 6
ERP: 1101029204
